FLIR T1020

FLIR’s new T1K offers outstanding infrared performance, with no sacrifice or compromise. FLIR’s flagship T1K redefines the limits of infrared imaging: true HD resolution, precision lenses like no others on the market, more than twice the thermal sensitivity of legacy uncooled systems, and the ergonomics and responsive user interface needed to make your workday easier.  The T1020 delivers the highest quality 1024 × 768 thermal images and offers amazing features at a price unimagined just one year ago!

Leasing Options
Category: SKU: T1020-28

Description

FLIR T1020 T1020-28 Infrared Camera Specifications:

Imaging and Optical Data
IR Sensor1024 × 768 (786,432 measurement pixels)
Thermal Sensitivity<0.02°C at +30°C
Field of View28° × 21°
Minimum Focus Distance0.4 m (1.32 ft.)
Image Frequency30 Hz
Spectral Range7.5 – 14 µm
4.3″ Display (Color)800 × 480 pixels
Display TypeCapacitive touch screen
Auto OrientationAutomatic landscape or portrait
Manual Image AdjustmentLinear based; possible to adjust level/span/max./min.
Image Presentation Modes
Image ModesThermal, Thermal MSX, Picture in Picture, digital camera
Visual ImageFull color
Infrared ImageFull color IR image
UltraMax™ SupportedYes
Measurement
Accuracy±1°C (±1.8°F) or ±1% at 25°C for temperatures between 5°C to 150°C
±2°C (±3.6°F) or ±2% of reading at 25°C for temperatures up to 1200°C
Temperature Range-40° to +2000°C
Measurement Analysis
Spotmeter10
Area5+5 areas (boxes and circles) with max./min./average
Measurement PresetsNo measurements, center spot, hot spot, cold spot, User Preset 1, User Preset 2
Measurement CorrectionEmissivity, reflected temperature, relative humidity, atmospheric temperature, object distance, external IR window compensation
Set-Up
Color PalettesIron, Rainbow, Rainbow HC, White Hot, Black Hot, Arctic, Lava
Storage MediaRemovable memory SD card (Class 10)
Image File FormatStandard JPEG, including digital photo and measurement data, on memory card
Time Lapse15 sec. to 24 hrs.
Video Recording/Streaming
Radiometric IR-VideoReal-time radiometric recording (RTRR) to memory card
Non-Radiometric IR-VideoH.264 to memory card
Visual Video RecordingH.264 to memory card
Radiometric IR-Video StreamingReal-time radiometric streaming (RTRS) via USB
Non-Radiometric IR-Video StreamingH.264 video using Wi-Fi or USB
Video OutHDMI compatible
Video, Connector TypeHDMI type C
Additional Information
USBUSB Micro-B: Data transfer to and from PC, iOS and Android
BatteryRechargeable Li-ion battery
Battery Operating Time>2.5 hours at 25°C (+68°F) and typical use
Charging SystemIn camera
External Power OperationAC adapter 90-260 VAC input, 50/60 Hz or 12 V from a vehicle (cable with standard plug, optional)
Power ManagementAutomatic power-off, user-configurable to 5 min., 20 min., or no automatic shutdown
Storage Temp. Range-40°C to +70°C (-40°F to +158°F)
Weight1.9 kg (4.3 lb.)
System Includes
Infrared camera with lens, memory card, battery (2 e.), neck strap, battery charger, power supply (including multi-plugs), HDMI-HDMI cable, USB cable, standard A to mini-B, hard transport case, calibration certificate, large eyecup, FLIR Tools+ license card, lens cap, user documentation CD-ROM, bluetooth headset, printed documentation

Warranty:  10-Year Detector Protection, 5-year Battery and 2-Year Parts & Labor
